Best production materials, such as using high-grade stainless steel produce chemical, fuel tank, fog tube and resonator, cooling jacket and protective shield, to guarantee reliability in daily application and long-durability of the equipment.

All seals, gaskets, and diaphragm in contact with chemicals solution are made of Teflon and Viton, we use anti-corrosive material, such as Teflon, Viton to guarantee long life use.

No spark plug ignition, quick start-up, less maintenance.

We supply machine together with accessories including different dosage nozzles, tool bag, spare parts, funnels etc, to guarantee customer can use the machine more than 6 years.

Equipped with a precision regulating valve adjust flow rate, no need change install different diameter nozzle for control flow rate.

Has been manufactured in accordance with the WHO Specifications on Equipment for Vector Control (WHO/VB C/89.973).

Application

Built to tackle the toughest jobs an urban environment has to offer.

Dispenses both water and oil-based chemicals, such as most pesticides, fungicides, disinfectants, miticides,
poultry vaccines, and Odor neutralizers.

Usable in a variety of environments:

• Living: apartment complexes, hotels,
• Public places: schools, parks, camp-grounds, shopping centers, restaurants,
• Industrial: warehouses, factories, food-processing plants,
• Agriculture: cattle barns, swine/poultry houses, grain mills, ..

Technical Specifications

• LONGRAY TS-35A(e)
• Body S.S
• Thermal Fogger
• Weight, empty 8.5kg
• Dimensions (L x W x H) 1440x270x315 mm
• Weight, empty.(shipping data) 13.5kg
• Dimensions (L x W x H),(shipping data) 1288x310x360 mm
• Chemical tank capacity 6 L
• Fuel tank capacity 1.5 L
• Fuel consumption 1.5-2L/h
• Performance of combustion chamber 22.1 kw / 30 hp
• Flow rate with oil 0-45 L/h (depends on nozzle diameter)
• Battery electricity 4 x1.5 V
• Pressure in chemical tank 0.25 bar
• Pressure in fuel tank 0.06 bar
