Description
- High extinguishing efficiency
- Allows intermittent and repeated operation
- Designed with a special engineered polymer valve head equipped with an over pressure mechanical safety valve
- Equipped with a rechargeable internal pressure cartridge
- An AFFF charge is enclosed in a separate internal cartridge, that instantly mixes with the water only at operation
- Internally coated with a special protective polymer lining, affording full protection against corrosion Operated with a high pressure rubber hose and pistol for high maneuverability and control
- Heat and electricity-isolated operation pistol and corrosion-proof base
- High quality surface treatment and red polyester coating
- Supplied with a special hanging wall bracket
Technical Specifications
Brand: Bavaria
Model: TORNADO-F
Type: External Pressure Cylinder Foam Fire Extinguisher (wheeled)
Extinguishing Agent: AFFF 3% pre-mixed foam concentrate (IA/IA rating)
Capacities:
45 L – compact industrial size
90 L – high-capacity protection for large risks
Fire Classes: A (solid combustibles) & B (flammable liquids)
Operating Pressure: Tested to 35 bar with bursting resistance > 70 bar
Propellant: Nitrogen (N₂) using external pressure cylinders
Hose Length:
45 L: 5 m reinforced rubber hose
90 L: 10 m reinforced rubber hose
Valve & Gauge: Chrome-plated valve head with mechanical over-pressure safety valve and pressure gauge
Mobility: Carriage with two rear rollers and one front directional wheel (chemical-resistant tyres)
Operating Temperature: +5 °C to +60 °C
Standards: Manufactured per European Standard DIN/EN 1866-3, TÜV certified
Warranty: 2 years against material and manufacturing defects
Directions for Use
Position the trolley close to the fire while maintaining a safe distance.
Remove safety pin to prepare for discharge.
Hold the insulated operating pistol and aim at the base of the fire.
Squeeze the pistol lever to release foam, sweeping back and forth until the fire is controlled.
