Technical data
Additional data
Rated input power: 850 W
Bit holder: 1/2″-20 UNF
Voltage, electrical: 110 V
No-load speed, 1st gear: 0 – 1,000 rpm
No-load speed, 2nd gear: 3,000 rpm
Power output: 430 W
Weight: 2.6 kg
Impact rate at no-load speed: 0 – 17,000 / 51,000 bpm
Rated speed: 800 / 2,060 rpm
Rated torque: 5.2 / 2.0 Nm
Drill spindle connecting thread: 1/2″-20 UNF
Chuck capacity, min./max.: 1.5 – 13 mm
Max. torque: 36.0 Nm
Drilling range
Drilling diameter in wood: 40 / 25 mm
Drilling diameter in steel: 13 / 8 mm
Drilling dia. in stone:20 / 15 mm
Drilling diameter in masonry:20 / 15 mm
Total vibration values (Drilling in metal)
Vibration emission value ah: 3 m/s²
Uncertainty K: 1.5 m/s²
Total vibration values (Impact drilling in concrete)
Vibration emission value ah: 15 m/s²
Uncertainty K: 2 m/s²
Total vibration values (Screwdriving)
Vibration emission value ah: 2.5 m/s²
Uncertainty K: 1.5 m/s²
Total vibration values (Thread-cutting)
Vibration emission value ah: 2.5 m/s²
Uncertainty K: 1.5 m/s²
Drilling in metal
Vibration emission value ah: 3 m/s²
Uncertainty K: 1.5 m/s²
Impact drilling in concrete
Vibration emission value ah: 15 m/s²
Uncertainty K: 2 m/s²
Screwdriving
Vibration emission value ah: 2.5 m/s²
Uncertainty K: 1.5 m/s²
Thread-cutting
Vibration emission value ah: 2.5 m/s²
Uncertainty K: 1.5 m/s²
Key Features
Rotation Control Clutch for overload protection and user safety
Durable Metal Gear Housing ensures longevity and performance
Speed Preselection & Forward/Reverse Controls for tailored use
Soft-Grip Handle & Ball Cable Grommet for enhanced comfort and durability
Auto-Lock Keyless Chuck enables quick, tool-free bit changes
