Technical Specifications

• Brand: Dongcheng

• Model: DMR04-12

• Rated Power Input: 1850 W — high-power motor for heavy-duty routing performance.

• No-Load Speed: 22,000 rpm — ultra-fast rotation for smooth and precise wood shaping.

• Maximum Milling Cutter Diameter: 12.7 mm — accommodates standard router bits.

• Net Weight: 6.0 kg — robust and stable for controlled operation.

• Included Accessories: Wrench (2 pcs), Straight Guide, Retainer Base Assembly, Template Guide, Trimmer Guide Assembly, Collets (6.35 mm & 9.52 mm), Carbon Brush, Color Box Packing.

Applications

The Dongcheng DMR04-12 Electric Wood Router is engineered to handle a wide range of woodworking tasks including:

• Edge profiling and trimming — rounded, beveled, or decorative edges.

• Grooving, dado & slot cutting — accurate cuts for joinery and cabinetry.

• Surface finishing & pattern work — smooth cuts for detailed designs.

• Furniture making & carpentry — shaping panels, doors, frame edges, and decorative mouldings.

Ideal for professional woodworkers, carpenters, workshops, and DIY enthusiasts who require consistent performance and precision.

Directions for Use

1. Safety First: Wear eye protection, hearing protection, and a dust mask before beginning work.

2. Bit Installation: Choose the correct router bit for your task (up to 12.7 mm) and secure it in the collet using the supplied wrench.

3. Set Cutting Depth: Adjust the cutting depth based on the material and desired finish.

4. Prepare the Workpiece: Clamp the wood surface firmly to avoid movement.

5. Start Routing: Switch on the router; allow it to reach full speed before contacting the work surface.

6. Controlled Movement: Guide the router steadily along the line or guide; avoid forcing the tool.

7. Finish & Clean: After routing, turn off the tool, allow it to stop completely, and clean off wood chips.

Safety Tips

• Keep hands away from the spinning bit at all times.

• Always use the guide for straight or repetitive cuts.

• Check that the bit is tightly secured before operating.

Key Benefits

• Powerful 1850 W motor delivers strong and efficient routing even in dense materials.

• High speed (22,000 rpm) ensures smooth, clean cuts.

• Wide 12.7 mm cutter capacity offers versatility for various woodworking bits and tasks.

• Complete accessory package makes it ready to use out of the box.
